| 1. Product parameters: | |||
| Size | 55” |  |
|
| LCD screen | A+ grade LG LCD panel | ||
| Active Display Area | 1209.6 x 680.4 mm | ||
| Screen resolution | 1920*1080P | ||
| Brightness | 350cd/m2 | ||
| Contrast ratio | 1200:1 | ||
| Display scale | 16:9 | ||
| Voltage | 110-240V/50-60HZ | ||
| Viewing angle | 178°/178° | ||
| Net weight | 68kg | ||
| Hardness of glass | Mohs 7 explosion-proof glass | ||
| Body material | Aluminum extrusions + aluminum alloy frame + 5mm toughened glass panel + cold rolled steel | ||
| Body color | Black, Silver, White (Optional) | ||
| 2. System parameters: | |||
| Non-touch version | |||
| Standalone version | Network version(Android or Windows) | ||
| USB version | Android | Windows | |
| Play mode | USB, SD card and HDMI optional | LAN, WIFI, Remote control information release system | |
| Interfaces | USB, HDMI optional | USB, LAN, WIFI, HDMI, VGA, 3G/4G optional | |
| Touch screen version | |||
| Android | Windows | ||
| Play mode | 10 point touch screen, LAN, WIFI, USB | ||
| Service life | Single point more than 50 million times | ||
| Interfaces | USB, LAN, WIFI, HDMI, VGA, 3G/4G optional | ||
| Video format | RM/MPEG2/MPEG4/H.264/RMVB/MOV/MJEG/VC1/,etc. | ||
| Picture format | JPEG,BMP.PANG | ||
| Audio | MP3,WMA,MP2,AAC,M4A,FLAC,APE,3GP,WAV , etc. | ||
| 3. Motherboard parameters: | |||
| Programme | Android OS | Windows OS | |
| CPU | RK3288/RK3399/A20 | Intel I3/I5/I7 | |
| Memory | 2G/4G | DDR3 4G/8G | |
| Hard disk | Flash 16/32G | 128G/256G/512G SSD solid state hard disk | |
| Extensible chute | 500G/1T Mechanical Hard Disk | ||
| Graphics card | Android HD | Integrated graphics,nuclear display | |
| Operating system | Android 4.4/5.1/6.0 | Windows 7/8/10 | |
| Network card | Integrated 10/100/1000M adaptive network card, wireless network card 802.11a/b/g/n | ||
| 4. Feature | |||
| 1. Structure | 1.1 Integrated design of display screen, touch screen and PC system | ||
| 1.2 High-permeability glass: The front panel protection glass adopts 5mm high -permeability tempered glass or AR anti-glare tempered glass, with light transmittance ≥97% and high light transmission | |||
| 2. Operation effect | 2.1 Infrared Multi-touch screen ,perfect 10-point touch, support handwriting and multi-point gestures, no deviation and no leakage | ||
| 2.2 The touch speed is less than 5ms, and the accuracy is perfect;the usage is simple,convenient, and very easy to maintain | |||
| 2.3 Anti-light interference to ensure the accuracy of operation (The machine works normal under direct light) | |||
| 3. Display | 3.1 Adopt special high-brightness LCD screen, brightness 300nit-400nit, visible under strong light, design life of 50,000 hours | ||
| 3.2 High definition image quality, screen resolution: 1920*1080p | |||
| 3.3 High dynamic contrast, the picture is clearer and the viewing angle is 178°/178° full perspective,all-round display of the screen in diferent directions is the same,no deviation | |||
| 4.Electronic structure | 4.1 The product uses the well-known manufacturer intelligent industrial control board, standalone / Android / industrial computer motherboard can be choosed. Support remote and local program management (optional) | ||
| 4.2 Adopt international famous brand industrial grade switching power supply, suitable for voltage in different countries around the world, which is safer, more stable, longer lifetime and high energy efficiency | |||
| 4.3 Configure the precision timer, which can be set in both Chinese English,etc. It can be set repeatedly according to the time of day, week and month | |||
| 5.Superb craftsmanship | 5.1 Good expandability: flexible configuration, can expand various functional accessories to meet customer need s | ||
| 5.2 Safety: aluminum alloy + sheet metal structure, no sharp edges, wear-resistant anti-corrosion paint process, overall anti-riot design | |||
| 5.3 Simple maintenance: each module is designed independently, easy to load and unload,and easy to maintain | |||
| 5.4 Easy installation: Power on and off when you press the switch, eliminating on-site installation and commissioning | |||
