| Model No: DS4920F | ||||
| 1. Product parameters: | ||||
| Panel | LCD size | 49” | ||
| Active Display Area | 1073.8 x 604mm | |||
| Resolution | 1920 x 1080pixels | |||
| Contrast Ratio | 1200:1（typ.) | |||
| Brightness | 380cd/m²(typ.) | |||
| Response Time | 8(Typ.) (G to G) (ms) | |||
| Frequency | 60Hz | |||
| Viewing Angles | 178°(H)/178°(V) | |||
| Life Time | 50,000hrs(min.) | |||
| 2. Motherboard parameters: | ||||
| Operation System | Version | Android 5.1 | ||
| Storage | RAM | 2G | ||
| SSD | 8G | |||
| Power Supply | Input | 100V~240V,50-60HZ | ||
| Power consumption(max.) | ≤120W | |||
| Standby power consumption | ＜0.5W | |||
| Environment | Working Temperature | 0℃～40℃ | ||
| Storage Temperature | -10℃～60℃ | |||
| Storage Humidity | 10%～90%RH Non-Condensing | |||
| Working Humidity | 20%～85%RH Non-Condensing | |||
| Working Hours | 7*24 hrs | |||
| Output Interface | EARPHONE | 1 | ||
| HDMI | 1 | |||
| Input Interface | TF | 2 | ||
| USB OTG | 2 | |||
| USB 2.0 | 1 | |||
| LAN-RJ45 | 1 | |||
| SIM | 1 | |||
| Structure | N.W(kg.) | TBD | ||
| G.W(kg.) | TBD | |||
| Outline Dimension (W x H x D) | 700 x 1780 x 73.7 mm | |||
| Package Size (W x H x D) | TBD | |||
| Shell material | Metal Shell | |||
| Shell color | Silver font frame | |||
| Language | OSD | EN./CH (etc) | ||
| Accessories | Power Supply Cable | 1 | ||
| Certificate of qualification | 1 | |||
| User Manual | 1 | |||
| Warranty Card | 1 | |||
| 3. Functions | ||||
| Functions | Dual 6/8/10-bit LVDS interface, support two screes that display different content, resolution up to 1920×1080 |
|||
| Built-in digital signage publishing control system | ||||
| Support image, video, music, dynamic text, PPT, interactive APP or software, dynamic sheet, website, static text、 APK、 office files, etc |
||||
| Support text, LOGO, date/time/week, weather and title. Support background picture |
||||
| Friendly use rgra phi cinterface for publishing play list, easy to realize play time, order, rate, content and other functions management. Get the play list display perfectly | ||||
| Intelligent Day Schedule, playback, timing playing, insert different playlist mode included. Support play list by timing publishing and preset publishing. Republishing historical play list. Delete expired play list automatically, save labor costs for updating play list by remote control, publishing playlist by USB flash disk directly or download the playlist to USB flash disk for publishing. Super multi- time timer switch on/off function, unattended. |
||||
| Play list preview, multi-audit, make sure to publishing play list accurately. Enterprise customization and expansion serve is optional. |
||||
| Landscape or portrait display switchable, smooth transition without black screen. | ||||
| Playlist preview, multistage auditing, present information correctly; Support | ||||
| Landscape or portrait display switchable, smooth transmission without black screen | ||||
| Terminal remote monitoring, real-time checking, provide rich business report & management reports. | ||||
| Powerful system health monitoring, support for fault warning, timely prompt notification of error messages. |
||||
| Terminal system remote upgrade, intelligent domain name resolution, security backup, convenient operation&maintenance | ||||
| Support WAN, LAN, VPN/WiFi/3G network publishing, cross-regional, trans- provincial, multi-network easy networking. | ||||
| 4. Real shots | ||||
